Digitax HD External 24Vdc Supply

An external 24 Vdc supply is required to power all the low voltage circuits within the drive.

The cable length between the 24 Vdc power supply and the drive should not exceed 10 m.
The 0V connection of the external 24 Vdc power supply should be connected to the same ground connection as the drive. Where this is not possible the 0V connection of the 24 Vdc power supply should be floating.

The working voltage range of the drive 24 V power circuit is as follow:

All Frame Sizes
Nominal operating voltage	24.0 Vdc
Minimum continuous operating voltage	20.4 V
Maximum continuous operating voltage	28.8 V
Minimum start up voltage	20.4 V
Maximum fuse rating	30A

24 Vdc typical input current and power requirements

Model/Option/Feature	Frame Size	Typical Input Current (mA) @ 24V	Typical Input Power (W)
Digitax HD M75X drive module*	1,2	894	21.5
	3	1039	25
DigitaxHD M75C Capacitor Module	All	240	4.9
SI-Option Module	Per Module	450	11
High Current Brake Output	All	1200	28.8
KI-Compact Display	All	10	0.24
KI-Remote LCS Keypad	All	73	1.75

* Typical 24 Vdc input current demand with inverter in the run condition, encoder connection and cooling fan(s) at full speed
